Exposure

Exposure XM7 Pre-Amplifier

Exposure XM7 Pre-Amplifier

$2,899.00 AUD
$2,899.00 AUD
Sale Sold out
Shipping calculated at checkout.
Color: Titanium

Features

  1. Large 200VA custom-made toroidal power transformer
  2. High quality all aluminium casework and extruded front panel
  3. High quality resistors and capacitors used in the signal path
  4. Audio output stages use discrete transistors
  5. High quality relays used for input selection
  6. 3.5mm and 1/4"" headphone outputs selectable by a switch at the back
  7. Moving magnet phono input, fixed level AV input and one line level input
  8. Two coax ( bnc) and two optical inputs and one class 2 USB input with DSD
  9. 2 pairs of pre-amp outputs for bi-amping or sub woofer
  10. Remote control
  11. Three year guarantee
  12. Available in black or titanium

Features

Specifications

Analogue Inputs

Pre Amplifier Output (input sensitivity / impedance / S/N)

  • AV input fixed level: 450mV @ 1KHz 12K ohms S/N 95dB
  • AUX/PH input MM: 2.5mV @ 1KHz, 47K ohms S/N 73dB
  • Frequency Response: 0.5dB 50Hz-20KHz. High pass roll off -1.5dB @ 20Hz
  • AUX 2 input line: 350mV @ 1KHz 14K ohms S/N output gain x3.75, +11.5dB
  • Total Harmonic Distortion: 0.005% at 1KHz: @ 1.3V RMS output
  • Frequency Response: 20Hz - 20KHz 0.5dB
  • Signal to Noise Ratio ref 1.3V RMS Output: 1KHz 92dB
  • Channel Separation @ 20KHz: 60dB
Digital Inputs
  • SPDIF inputs BNC Coax Optical: 32 - 192KHz @ 16-24 bits
  • Total Harmonic Distortion: 0.005% at 1KHz @ 1.3V RMS output
  • Signal to Noise Ratio ref 1.3V RSM Output: 1KHz : 98dB
  • USB input: Linear PCM 44K1 - 192KHz @ 16-24 bits DSD x64 (DoP) Asynchronous transfer from host
Headphone Output
  • Output Impedance: 10 ohms
  • Maximum Level into 33 ohms: @ 1KHz 0.1% THD: 5V RMS
  • Total Harmonic Distortion: @ 2V output, 1KHz: 0.03%
  • Maximum Level into 330 ohms: @ 1KHz 0.1% THD: 8V RMS
  • Total Harmonic Distortion : @ 2V output, 1KHz: 0.01%
General Specifications
  • Mains Supply: 110/120V or 220/240V @ 50/60Hz (factory set)
  • Power Consumption: 25W
  • Dimensions (WxHxD): 218mm x 89mm x 363mm (inc knob)
  • Net Weight (unpacked): 5kg
  • Gross Weight (packed): 6kg

What's in the box

1x Exposure XM7 Pre-Amplifier
