Audio Technica AT-LP7X Belt Drive Turntable

Name: Audio Technica AT-LP7X Belt Drive Turntable
Brand: Audio Technica
Price: 1799.00 AUD
Availability: InStock

$1,799.00 AUD

Sale Sold out

Shipping calculated at checkout.

Quantity

The AT-LP7X fully manual belt-drive turntable blends analog excellence with style and versatility. Featuring a dense MDF plinth and acrylic platter to minimise unwanted resonance and vibration, this elegant, matte-black turntable delivers sound that’s just as clean and refined as its appearance.

In designing the LP7X, we paid special attention to chassis geometry, ensuring that the platter, spindle, and tonearm were optimally positioned for accurate, distortion-free tracking. The J-shaped aluminium tonearm, inspired by classic A-T models of the 1960s and ’70s, features a dual-axis gimbal with precision ball bearings to further enhance tracking performance.

The turntable comes with our AT-LT10 headshell and AT-VM95E BK (black) cartridge with 0.3 x 0.7 mil elliptical stylus, providing excellent channel separation and low distortion for outstanding tonal quality. For easy customisation, the stylus can be replaced or interchanged with other styli in the VM95 line, offering a wide choice of options for every budget and application.

Combined, the turntable’s AT-VM95 cartridge, VTA (vertical tracking angle) adjustment, and 16 g sub counter weight expand your configuration options. Upgrade to a more refined VM95 stylus or experiment with different cartridge/headshell combinations (up to 23.5 g total). Add the optional 32 g sub counter weight (available separately) and work with combinations up to 28.5 g.

Features

Fully manual, belt-drive operation with two speeds: 33-1/3 and 45 RPM
Heavy 40 mm MDF (medium density fiberboard) cabinet construction reduces resonance and vibration for clearer sound
Motor features a speed-sensor system to maintain accurate platter rotation speed
20 mm-thick, high-density acrylic platter offers high rotational inertia to spin records at a consistent speed (no platter mat required)
J-shaped tonearm with adjustable VTA (vertical tracking angle)
AT-VM95E BK (black) cartridge (0.3 x 0.7 mil elliptical stylus) pre-mounted to the lightweight AT-LT10 removable headshell
AT-VM95 cartridge is compatible with most VM95 Series replacement styli, offering a wide choice of options for every budget and application
Included 16 g subcounterweight provides an expanded cartridge/headshell weight range of 14.0–23.5 g
A larger 32 g subcounterweight is available separately to enable the use of cartridge/headshell combinations up to 28.5 g
Adjustable anti-skate control to counter the inward force the styli experiences during playback
Built-in switchable phono pre-amplifier with selectable modes for MM (moving magnet) or MC (moving coil) cartridges
Includes dual RCA (male) to dual RCA (male) stereo cable with ground, 45 RPM adapter, and removable dust cover

Specifications

Type : Belt-drive, fully manual operation
Motor : DC servo motor
Drive Method : Belt Drive
Speeds : 33-1/3 RPM, 45 RPM
Turntable Platter : 20 mm (0.79") thick acrylic platter Wow and flutter
Wow and Flutter < 0.1% (WTD) at 3 kHz (JIS)
Signal-to-noise ratio > 60 dB

Output Levels

PHONO : 4.0 mV nominal at 1 kHz, 5 cm/sec

LINE : 252 mV nominal at 1 kHz, 5 cm/sec

Phono Pre-amp gain
MM: 36 dB nominal, RIAA equalised
MC: 56 dB nominal, RIAA equalised

General

Power consumption
5.5 W
Dimensions (W × D × H)
450 mm × 352 mm × 157 mm
Weight 7.6 kg Operating Temperature5°C to 35°C (41°F to 95°F)
Replacement Stylus : AT-VMN95E BK (sold separately)
Replacement Headshell : AT-LT10 (sold separately)
Replacement Belt : AT-LP7X exclusive belt (sold separately)Tonearm
Type : Static balanced J-shaped tonearm
Effective Length : 247 mm Overhang15 mm
Maximum Tracking Error Angle < 2.0°
Tracking Force Adjustment Range 0.0 - 4.0 g
Applicable Cartridge Weight : 14.0 to 19.5 g (without sub counterweight)17.5 to 23.5 g (with sub counterweight (light))22.0 to 28.5 g (with sub counterweight (heavy)**Please note that the sub counterweight (heavy) is sold separately.

Cartridge

Model AT-VM95E BKTypeVM
Recommended Loan Impedance 47,000 ohms
Output Voltage 4.0 mV (1 kHz, 5 cm/sec)
Stylus Shape 0.3 × 0.7 mil bonded elliptical stylus
Cantilever : Aluminium pipe
Tracking Force : 1.8 to 2.2 g (standard 2.0 g)
Weight : 6.1

AC Adaptor

Rated Input Voltage : 100 to 240 V AC
Rated Input Current : 0.6 A max.
Rated Frequency : 50 Hz / 60 Hz
Rated Output Voltage : 12 V DC
Rated Secondary Current : 0.5 A
Cable LengthApprox. 1.3 m
Headshell : AT-LT10
Weight : Approx. 10.7 g (0.38 oz) (including lead wires)Approx. 10.0 g (0.35 oz) (excluding lead wires)
Overhang Adjustment- 5.5 mm to + 2.5 mm (when using AT-VM95E)
